Laser Metal Cutting Machines for Small Business in Stock

Laser Machine Detail


metal cutting laser machine adopted pulsed xenon lamp as its pumping source and emits laser beam with high energy density. The laser beam is focused on the surface of work-piece as an ultrafine focus facula, and causes the irradiated area instantly melted and vaporized. The CNC system automatically controls the metal cutting laser machine to achieve the cutting mission.

This metal cutting laser machine is constituted with laser technology, CNC technology and mechanical technology. YAG laser cutting machine is designed for metal sheet cutting and applicable to processing stainless steel, carbon steel, aluminum and pipes. It has been widely used in plate processing, machinery manufacturing and precision processing,etc.

Features and Advantages


1.Mold-free, capable of various kinds of Complex processing with lower cost, all we have to do is to finish CAD drawing with computer;
2.Stable and reliable CNC system, easy operation;
3.Lower cost compared with CO2 laser, operating cost 1:8 and Maintenance cost 1:10 ;
4.High cutting efficiency, used for thin metal plate cutting, high procession accuracy, small kerf and beautiful cutting edge;
5. ]Independent researched YAG laser generator and Laser cutting head, dust-free assembling process, high damping planer type machine, high precision servo system, these Guaranteed stability and reliability.

Application


laser cutting machine is good at cutting various metal: Stainless Steel, Mild Steel , Carbon Steel , Alloy Steel , Spring steel , Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Sheet, Copper Plate, Brass Plate, Bronze Sheet, Gold Plate, Silver Sheet, Titanium Plate, Metal Tubes and Metal Pipes, etc.

Quality Control


We always pay more attention to the quality of laser cutting machine. Standard quality control system and team are responsible to insure the product quality in every process with different instruments like laser interferometer and laser powermeter. In the mechanical assemble process, the laser interferometer, laser callimator, dial indicator and marble plate are used; In the laser assemble process, the laser powermeter and optical microscope are adopted.

After-Sales Service


Technical support online service provided.
Technical files service provided.
On-site training service provided.
Spare parts replacement and repair service provided.

Quick Details


Application: Laser Cutting
Condition: New
Laser Type: YAG
Applicable Material: Metal, Other
Cutting Thickness: 0-8mm
Cutting Area: 1200x1200mm
Cutting Speed: 0-6m/min
CNC or Not: Yes
Cooling Mode: Water Cooling
Control Software:CypOne
Graphic Format Supported: DXF, DXP, PLT, Other
Place of Origin: Anhui, China (Mainland)
Brand Name: ACCURL
Certification: CCC, CE, ISO, TUV
After-sales Service Provided: Engineers available to service machinery overseas
Laser power: 600W
Laser Wavelength: 1064nm
Pulse Frequency: 1-450Hz
Repeat Location Accuracy: ±0.02mm/m
Location Accuracy: ±0.03mm/m
Power supply: 3-phase 380V±10%,50Hz
Min.cutting line width: 0.15mm
Control system: Motion control card+PC
Equipment Power: 40KW
Machine dimension: 2300x2100x1500mm

Technical Parameters


Technical Items

Parameters laser cutting machine

Laser MediaNd:YAG

Laser Power

600W
Applicable MaterialMetal Sheet
Working Area1200*1200mm
Cutting Thickness≤8mm
Cutting Speed≤6m/min
Laser Wavelength1064nm
Location Accuracy±0.03mm/m
Repeat Location Accuracy±0.02mm/m
Min.cutting Kerf0.15mm
Equipment Power (Total)40KW
Control SystemMotion control card+PC
Control SoftwareCypOne
Support FormatDXF, AI, NC, G, TXT, etc.
Cooling ModeWater Cooling
Power Supply3-phase 380V/50Hz/20KVA
Machine Weight1500KG
Machine Dimension(L*W*H)2300*2100*1500mm
RemarkOptional Laser Power :

600W / 750W / 850W

Optional Cutting Area :

1200*1200mm(YAG1212) / 2500*1300mm(YAG2513) / 3000*1500mm(YAG3015)

Optional Configuration :

Standard / Standard+Cutting Circular Tube / Standard+ Cutting Square Tube
