Application: Laser Cutting
Laser Type: Fiber Laser
Applicable Material: Metal
Cutting Thickness: 0-30mm
Cutting Area: 6m
Cutting Speed: 35m/min
CNC or Not: Yes
Cooling Mode: Water Cooling
Graphic Format Supported: AI, DXF, PLT
Certification: CE, ISO, SGS, FDA,BV,TUV
After-sales Service Provided: Engineers available to service machinery overseas
Laser power: 500W / 1000W /1500W/ 2000W / 3000W/4000W
Keyword: Laser Cutter
Warranty: 3 years
Size: 12000*1800 *2400mm
Cutting length/diameter: 6m/20-200mm
Laser source: IPG/MAX
Servo motor: Japan Yaskawa servo motor
Laser Head: Swiss Raytools
Bearings: NSK bearings
NO.1 Characteristics of our laser cutting machine
1. Fiber laser tube cutting T model, a professional machine designed for tube processing, has a max cutting length as 9000mm and max cutting diameter as 200mm.
2. Electric servo motor-driven chucks at both front and rear ends, with clamping diameter ranging from 20mm-200mm, are designed with extra-long mechanic claw to reduce material waste.
3. The machine is applicable for the processing of round, square, rectangular, ellipse tubes and tubes with various shapes.
4.The front material collector is designed to collect finished products for further sorting.
5. Can cut lines and holes with different diameters from different directions on the pipe,and meet centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.
6. Can cut column Crossed Lines at the end of branch pipe,and meet centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.
7. Can cut inclined section at the end section of the pipe.
8. Can cut branch pipe intersected with the main circular pipe.
9.To realised angel groove face,square hole,waist-shaped holes cutting.
NO.2 Machine Application Field
1.Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel tube, Mild Steel tube, Carbon Steel tube, Alloy Steel tube, Spring Steel tube, Iron pipe, Galvanized Iron, Galvanized pipe, Aluminum Pipe, Copper pipe, Brass pipe, Bronze Pipe, Gold Pipe, Silver Pipe, Titanium Pipe, etc
2.Application Industries: BODOR Fiber Laser Cutting Machines are widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.
|Cutting length||6m(9m/12m for your reference)|
|Max moving speed||100m/min|
|Max Cutting Speed||35m/min|
|Min Line Width||0.1mm|
|Cooling Way||Water cooling|
|Driving and Transmission Way||Imported Servo Motor|
|Continuous Working Time||24 hours|
WIFI wireless control
To provide speedy service, we add WIFI function for our technician operates troubleshooting and ajustsd parameters remotely. Checking laser source parameters to analysis failure causesChecking cutting parameters to analysis and adjust new parameters
Switzerland RAYTOOLS Laser Head
1 .Optimization of the optical configuration Smooth and efficient air flow design
2. Rotary Knob focus adjustment. More easy and flexible. Adjust range 20mm, accuracy:0.05mm.
3.Drawer style mirror stand, changing protect glass faster and more easily.
4.Collimating lens and focal lens adopt compound lens, to obtain the optimal optical quality and the cutting effect.
Japan Yaskawa Servo Motor
Using the SoMove setup software: The SoMove setup software could do the control loop configuration. optimization,and maintenance, for the Lexium Easy 26 servo drives in automatic or manual mode by oscilloscope function,as same as other Schneider Electric drives.Equipped with SoMove software for easy setup and adjusting Driver Printed circuit board with coating protection,improve the reliability in the polluted environment
France Schneider Electronic Component
Circuit protection against short-circuit currents,Circuit protection against overload currents,Breaking and industrial disconnection as per standards IEC/EN 60947-2.Overvoltage resistance,High performance limitation,to fast closing independent of the speed of actuation of the toggle.
Japan SMC pneumatic components
Stepless control of air pressure proportional to an electrical signal.Serial communications specifications.Compact/lightweight (Integrated communication parts).
Optical fiber transmission, don't need to adjust the laser path. IPG, Maxphotonics fiber source. Wavelength range:1070～1090nm Beam quality TEM00 (M2<1.8) Forced air/Water cooling More than 100000 hours work-life of pumped
Auto Lubrication System
Electrical lubrication is a kind of Gear pump with rational construction , great performance , complete functions. Controlled by main machine system which could inspect the liquid level of the oil tank, the pressure of oil transportation , and setting the lubrication periodicity. Effective avoid rust and ensure the cutting accuracy .
