tube cnc cutting machine & metal plate laser processing equipment

tube cutting equipment

Product Description


Tube CNC cutting machine & metal plate laser processing equipment

Metal Tube Fiber CNC Cutting Machine Advantages

1) Can cut lines and holes with different diameters from different directions on the pipe, and meet centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.

2) Can cut column Crossed Lines at the end of branch pipe, and meet centrifugal and non-centrifugal vertical intersection condition for branch and main pipe axis.

3) Can cut inclined section at the end section of the pipe.

4) Can cut branch pipe intersected with the main circular pipe.

5) Can cut variable angle bevel surface

6) Can cut square hole, waist-shaped holes and circular hole on the pipe.

7) Can truncate the pipe.

8) Can cut all kinds of graphics on the surface of the square pipe.

>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>

Why use Metal Tube Fiber CNC Cutting Machine ?

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

(1) Fiber laser cutting machine for metal precise cutting powered by fiber laser technology. The quality fiber laser beam results in faster cutting speeds and higher quality cuts compared to other cutting solutions. The key advantage of a fiber laser is its short beam wavelength (1,064nm). The wavelength, which is ten times lower than that of C02 laser, generates high absorption into metals. This makes the fiber laser become a perfect tool for cutting metal sheets of stainless steel, carbon steel, mild steel, aluminum, brass, etc.

(2) The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser. The fiber laser beam is capable of cutting reflective metals with much less energy as the laser is absorbed into the metal being cut. The unit will consume little to no energy when not active.

(3) Another advantage of fiber laser is the use of highly reliable single emitter diodes with projected lifetimes greater than 100,000 hours of continuous or pulsed operation.

(4) Laser software allows for the capability to control power, modulation rate, pulse width and pulse shape giving the user full control of the lasers capabilities.

******************************************************************************************************
Technical parameter of Metal Tube Fiber CNC Cutting Machine

   Laser PowerIPG        500W/1000W/2000W/3000W
Rofin     1500w/2000w/3000w
Raycus  500w/750w/1200w
   Machine Transmission
System
*Beckhoff/Japan strong power YASKAWA full closed loop every 0.1mm step under control*TBI high accuracy ball screw-0.01mm accuracy in moving process--mini circle cutting best
Optics System* LASER MECH/ German PRECITEC   -0.01second adjust time--0.01mm different point will ask head to adjust to best point cutting
*Dynamic focus - even min wave keep same top level cutting result
*Nozzle diameter from 1.5mm-2.5mm for different kerf cutting inquiry
Cutting thicknessCarbon steel      0.1-20mmStainless Steel    0.1-12mm

AL                    0.1-12mm

Controlling SoftwareBeckhoff / CypCut
       Software Support*AutoCad file import directly without size change and modify
*Machine software to make material in max cutting use
*Optimal Track Intelligent  Adjusting
shortest path least time save gas cost and cutting time
Assistant Gas* Air,nitrogen,oxygen freely change system
* Less gas cost control under different cutting thickness
Cutting speed0-60m/min
Position Accuracy0.03mm
Water Cooling SystemDual temperature dual control water chiller with purification system
Driving ModeDouble ball screw driving / Double gear rack driving
Working Table StructureFixed Working Table / Pallet Changer

Metal Tube Fiber CNC Cutting Machine Speed

Materialm/min
carbon steel 1mm8
carbon steel 2mm4.2
carbon steel 3mm2.1
carbon steel 4mm1.2
stainless steel 1mm7.2
stainless steel 1.5mm3
stainless steel 2mm1.8
galvanized sheet0.8mm5
galvanized sheet1.2mm2.6
galvanized sheet1.5mm1.8

Metal Tube Fiber CNC Cutting Machine Cost

Electricity cost1-3KW
Laser gasNot
Assisted gasOxygen/Nitrogen/compressed air
The parameters showed are based on the client actual working situation,only for reference!
The assisted gas will be used according to the different materials (such as stainless steel and carbon steel).

Application Industry of Metal Tube Fiber CNC Cutting Machine

It is applicable to sheet metals, elevator,kitchenware,elevator,fitness equipment,agricultural and forest machinery,food machinery,hardware, advertising, decoration, gifts, lighting lamps, medical instruments etc.

******************************************************************************************************

Application Materials of Metal Tube Fiber CNC Cutting Machine

Mainly for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.

******************************************************************************************************
We have the spirit of " high quality and low price, sincere service, create value for customers"business philosophy.

Jinan Dekcel CNC Sincerely Service For You.
*******************************************************************************************************
Quality control:
Before the order can be confirmed finally, we would strictly check the material, dimension of the sample step by step.
Our salesman, also as a order follower,would trace every phase of production from the beginning.
We have a QC team, every product would be checked by them before packed.
We would try our best to help clients solve problems.

******************************************************************************************************

FAQ

Question 1: I want to buy this machine,what suggestion can you give?
Answer: Please tell me:what material do you process? What's the size of your material?(Better show me your product picture)

Question 2: What's the delivery cost & time?
Answer: Please tell me your sea port name,i check shipping cost. After production,we'll deliver ASAP.

Question 3: Have you exported to our country?
Answer: We have been in this field for 11 years,we have CE,CO,ISO,FDA certificates,have exported to Europe,South America,Arab,Asia,Russia,Spain,Australia and many more countries.

Question 4: This is the first time I use this kind of machine, is it easy to operate?
1) User manual, CD with video will along with machine for training you how to install, how to use, and how to maintains,
2) Moreover, Skype, Team viewer online service is available for you,
3) Free training will offer you on our factory, Engineer is available to offer international service!
4) Local agent service available is extending all over the world!

If there is still have any question, please contact us by e-mail / skype/ phone /trademanager online service at any time.

Question 5: If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period if machine have any problem.
If the parts less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.

Question6: How can I become a Agent ?
Agent all over the world is wanted, welcome to visit our factory to know more of each other for start our long term cooperation!

******************************************************************************************************

Our Package Advantage:

1.Our wooden case is after fumigation treatment.Needn't timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
Avoiding all damages that could happen in the delivery process.Then we'll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.

******************************************************************************************************

Warranty and after-sale service:

1.12 months guarantee for whole machine free of charge

2.7*24 hours technical support by e-mail

3.Calling or door-to-door service,professional training to your workers

4.Use friendly English software, user manual and detailed Videos/CD

5.Priority to become our agent in your city,we offer you our factory price
