1. Excellent quality of light beam
2. Highly cutting speed: the 2 times by co2 laser cutting machine under the same power.
3. Very high stability and efficiency of photoelectric conversion
4. Very low using cost and maintenance cost
5. Convenient product operation and maintenance
6. Very strong soft optical effects: compact volume and structure
7. Gantry double driving structure, high damping machine tool bed, good rigid,
8.This model adopts imported AC servo system driver and imported transmission system, the moving structure of machine tool adopts imported gear and rack transmission, linear guide track for guiding, ensuring the high speed,high precision and high reliability of equipment.
9. Rack and guide adopt fullly enclosed protective device, which prevents oil free friction movement and dust pollution, enhances using life of transmission parts and ensures the precision of machine tool movement.
10. Professional laser cutting machine, cnc control system, computer operation, can ensure the cutting quality, and more convenient for cutting work.
11. Automatic swiching table configuration, which shortens the standby time, and effectively enhances the working efficiency more than 30%.
12. Fully enclosed protective cover,using safety.(Enclosed Model)
Imported Germany Laser Cutting Head
Selection of Germany Laser cutting head brings Z axis servo function. It’s servo sensor adopts capacitive sensing sensor monitoring and provide cutting auto focusing features of high sensitivity, stability and fastness. With characteristics, it makes the fixed length cutting head body install optical lenses with different focal lengths so that the focus and the nozzle height can be adjusted flexibly.
Fiber laser cutting machine sample show
Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring Steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc
The Fiber Laser Cutting Machines are widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.
Application: Laser Cutting
Laser Type: Fiber Laser
Applicable Material: Metal
Cutting Thickness: 0-30mm
Cutting Area: 1300*2500mm
Cutting Speed: 0-40000mm/min
CNC or Not: Yes
Cooling Mode: Air Cooling
Control Software: Leetro
Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin: Anhui, China (Mainland)
Brand Name: accurl
Certification: CE, ISO
After-sales Service Provided: Engineers available to service machinery overseas
Name:CNC Laser Cutting Machine
Product name: metal fiber laser cutting machines factory
Laser power: 500W / 1000W / 2000W / 3000W
Laser tube: IPG or Raycus fiber laser generator
Keyword: Fabric Laser Cutter
Function: Cutting Metal Materials
Working area: 1300mmX2500mm
1.Guarantee for 3 years.
2. Maintenance free of charge for 3 years .
3.We will provide the consumable parts at an agency price.
4.24 hours online service, free technical support.
5.Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions, pls kindly tell me.
6.We have manual instruction and CD (Guiding Videos) for software Installation, operation and machine's using and maintenance.
Fiber laser cutting machine parameter
|Laser Type||Imported Original Fiber Laser|
|Laser Maximum Power||500W||1000W||2000W||3000W||4000W|
|Max. Cutting thickness||≤8mm||≤12mm||≤16mm||≤18mm||≤20mm|
|Total Power Consumption||<14KW||<18KW||<22KW||<26KW||<30KW|
|Max.cutting speed||0-30m/min(Depending on the material and thickness)|
|X, Y, Z Axis Orientation Precision||≤±0.05mm/m|
|X, Y, Z Axis Repeat Precision||≤±0.03mm /m|
|Min line width||≤0.15mm|
|Maximum Empty Running Speed||120m/min|
|Driving way||Imported servo motor|
|Transmission way||Y-axis import gear rack double driver, X-axis imported ball screw|
|Worktable Max Load||1600 KGS|
|Cooling System||Water Cooling|
|Continous working time||24 Hours|
|Power requirements||380V/3 Phases /50Hz or 60Hz|
|Power requirements Outer size (L*W*H)||4500x2000x1800mm|
