professional cnc fiber laser cutting machine for brass sheet japanese yaskawa servo motor

cnc laser cutting machine

Detailed Product Description


Model Number:KJG-1530DT-500W ACCURLWorking Range:1500x3000mm
Laser Type:China Raycus Fiber YLS-500wLinear Guide:Taiwan HIWIN
Table-driven System:Japanese Yaskawa Servo Motor & Driving SystemKeywords:CNC Laser Cutting Machine

Open Type 500W CNC Laser Cutting Machine for 1mm Brass Sheet Metal Cutting Laser Machine

Product Introduction

Our ACCURL team now introduces its newest generation in tube and profile processing technology – the fiber laser tube cutting system. Technological innovation has brought us the Smart KJG Series. With exceptional reliability and high beam quality, our fiber laser cutting machines continue to be leaders amongst the competition.

STANDARD EQUIPMENT

• lUser friendly Cypcut Windows CAD/CAM CNC control unit.

• lUnique features:

• Very easy to operate.

• Quick and easy installation.

• Low investment and operating costs.

• The most cost-efficient solution for every requirement.

• Flexible beam path

• High output power

• High optical quality

• Up to %300 faster cutting

• High wall plug efficiency (>%30)

• Copper, brass cutting ability

• Advanced Raytools cutting head (with air cross blast).

• High performance and high accuracy rack and pinion system.

OPTIONAL EQUIPMENT

• FAGOR 8055 CNC System(Servo motor)

• Shuttle Table and Clean Room

• Table size 1500x4000mm

• Table size 2000x4000mm

• Pipe cutting system(φ220mm / 3000mm)

• Cutting Head from PRECITEC- Manual(500w-1500w)

• USA.IPG / nLIGHT / China.Raycus Fiber Laser Power(500w-2kw)

Laser Cutting Machine Better Performance, More Rigid and Durable Construction

A. Top quality components
B. Integrated circuit (professional circuit board)
C. Rigid machine tool and mass loading working
Laser Cutting Machine High Efficiently
A. Travelling speed increases utmost
B. Cutting software functions improved
C. Nesting software optimized cutting patch (can directly read CAD)
Laser Cutting Machine More Safe and Save Labor
A. Machine structure and electric circuit design and assembly conform with CE and FDA
B. Assistant loading system and wireless remote control handle
C. Lubrication system
Laser Cutting Machine More Optimized Technique
A. Different laser cutting heads and optimized nozzle
B. Three gas source and dual-pressure gas route
C. Strong software support
Laser Cutting Machine Higher Precision
A. Fully closed loop controlling system
B. Cutting compensation
C. Top accuracy testing device

Advantages :
1) Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.

2) High cutting speed: Cutting speed is more than 20m/min

3) Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

4) High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber optic laser cut has three times photoelectric conversion efficiency

5) Low cost & Low main tenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;

6) Easy operations: fiber line transmission, no adjustment of optical path;

7) Super flexible optical effects: Compact design, easy to flexible manufacturing requirements.

Main Features of CNC Fiber Laser Cutting Machine for Cutting Sheet Metal and Metal Tube

1. A camera is installed inside the protective cover to oversee real-time operation within the cover and shoot any possible problems timely.
2. The machine owns perfect cooling system, lubrication system and dust removal system, which make sure the machine can operate stably,efficiently and durably.
3. There is a casting beam with the machine that makes it more rigid, stable and shockproof.
4. The machine is capable of automatic height adjustment to maintain constant focal length and stable cutting quality.
5. The machine can be used for cutting a variety of metals with excellent and stable cutting quality.
6. With a specialized CAD / CAM automatic programming software and automatic nesting software, it is possible to maximally g save raw materials.

Application Materials:

Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc.

Application Industries:

Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.

Techincal Parameter

ModelKJG-1530 / IPG 500w
Maximum cutting capacityMild steel6mm
Stainless steel2.5mm
Aluminyum2mm
Copper1mm
Laser PowerYLR-500Watt
Max running speed40/min
Work piece dimensions1500 x 3000mm
Rapid traverse (X and Y axis)105 m/min
Acceleration1.2G (12m/s2)
Absolute positioning accuracy± 0.03 mm
Max. load capacity1550 kg
Fume extractor1000 m3/hour
Laser Cutting HeadRayTools BM110 from Switzerland
Feed rateProgrammable up to 30 m/min.
Applied MaterialsThin mild steel, Stainless steel, Aluminum, Copper plate
