mini portable small type 9015 1218 1224 metal plasma cnc cutting machine

mini cnc plasma cutting machine

Features of cnc plasma cutting machine:


1.Welded lathe bed of thick profiled steel, more solid and stable.
2.Perfect lathe table design, 10mm steel plates fixed on lathe table covered by cast sheath.The level difference of platform remains in 0-1.5mm.
3.Advanced material inclined discharging design.
4. CNC system configuration high, automatic arc, stable performance, the success rate of 99% arc.
5. Support Fastcam software such as the standard G code path generated file can also be read by software conversion software
such as AUTOCAD generated DXF formats. U disk exchange control system processing files, easy to operate.
6. Plasma torch power supply and supporting all famous brands, a number of national patents by the manufacturers.

Machine Specifications:


Name: Metal Plasma Cutting Machine
Power: USA or Huayuan Power
Working Table: Serrated Table(Sawtooth)
Motor: Stepper(Servo Option)
Control System: Starfire or Start
Voltage: 220V for Machine, 380V for Plasma Power
Cutting Thickness: 0-50mm
Siutable Material: Carbon Steel, Stainless Steel, Copper, Aluminum
Rails Transmit: Taiwan Hiwin or Abba
Machine Structure: Channel Steel Lathe Bed/Heavy Duty
Transport Package: Standard Export Plywood Case
Specification: 1300x2500mm
Origin: China

Model1325 1530 2030 (cnc plasma cutting machine)
Working area1300x2500mm or 1500x3000mm or 2000x3000mm
working tableserrated table(sawtooth)
Machine StructureChannel steel lathe bed/heavy duty
RailsTaiwan Hiwin Square rails (ABBA option)
MotorStepper motor and driver (Servo option)
with air compressorTo cool the cutting head, blow away the slag
Cutting speed15-20m/min
Cutting thicknessDepend on current of plasma power source
Power supplyHuayuan Power (USA Hypertherm for option) 63A 100A160A 200A
Control systemSTARFIRE or START
SoftwareFastcam /Artcam/Type 3
Steel blade saw tooth mesaRay plug drives 860
Working modeNon-contact arc
Automatic striking the arcstable performance, striking the are success rate above 99%.
Repeat positioning accuracy±0.05mm
Process precision±0.3mm
File transfer modeUSB interface
Input voltage3 phase 380V for power source, 220V for machine
Packinginternational standard plywood case packing.
Machine size3520x2320x1340mm (as 1325)

Guarantee:


1.12 months guarantee of the whole machine
2.Main parts(excluding the consumables)shall be changed free of charge if there is any problem during the warranty period.
3.Lifetime maintenance free of charge
4.We will provide the consumable parts at an agency price when you need replacement
5.Machine has been adjusted and tested before delivery
6.Our staff can be sent to your company to install or adjust if necessary

Payment terms:


T/T 30% payment for deposit, after the machine finished, we will take the testing videos for you to check the machine, after you satisfied the machine you pay the left 70% payment. Then we will delivery the machine.

After-sale service:


1. 24hours Technical support by Email or Calling.
2. English manual and CD video for machine using and maintaining.
3. Hardware: 1 years for machine (without person damaged).
Software: Whole life on update for free.
Maintenance and technological support: 12 month
