Name | Item | Parameter |
Intensifier Pump
| Model | WMT3742Z |
motor | SIEMENS | |
Method of Direction Regulation | Electronic direction regulation | |
Pressure Range | 50-420MPA, continuous pressure is 330-380Mpa | |
Maximum Flow of Hydraulic Pump | 90 L/min | |
Maximum Discharge Capacity | 3.7 L/min | |
Maximum Diameter of Gem Nozzle | 0.33 mm | |
Power of Master Motor | 37 KW | |
Power Source | 380V/50HZ, also work at 220V/60HZ, 415V | |
Cutting Table | X axis Characteristic | use strong 10MM steel, 3000MM cutting range. The cutting table width is 3200mm |
Y axis Characteristic | Cast iron is used as the foundation base , 2000MM cutting range . The cutting table length is 3200mm. | |
Z axis Characteristic | Z axis double linear guide and four sliding block , 180MM, CAN DO 200MM | |
Control Accuracy | ±0.01mm, cutting accuracy is ±0.1mm, reposition accuracy: ±0.02mm, max travelling speed:6000mm/min, we have new technology that can make the travelling speed 20-30m/min. | |
linear guider | TAIWAN TBI BRAND | |
Table Ctructure | can be delivered by one 40'FCL container | |
Driving Way | Servo drive system | |
CNC system | Ncstudio ,Fagor | |
Servo Motor | SIEMENS motor | |
Cutting Head | Casting structure and Concrete structure | |
Sealing Way | soft dustproof cloth on X,Y,Z axis,the sealing result will be better,and there is a oil tank under the cutting table,the linear guider no need maintainence. | |
Loading Weight Water Tank | Wall thickness is 6mm,using fluorocarbon coating, Can antirust at least 5 years. | |
CNC Controller | Control Method | CNC |
Display Size | 19inch LCD | |
Model of Cutting Text | DXF | |
Model of Computer | Industrial Control Computer | |
Operating System | Windows 7 | |
PLC | SIEMENS | |
Cutting Software Advantage | Auto save and transfer common parameter | |
Controller Displace | Can be fit to suitable place at own will | |
Automitic Abrasive Feeder | Founction | Sand storage and sand delivery |
Operating | No need electrocnic control,sample operation | |
Capacity | 200 kg for 8 -10hours | |
Pressure | 0.3-0.6Mpa compresses gas pressure | |
Color | White | |
Deionization System | Water pressure | 0.15Mpa~0.6Mpa |
Water temperature | 5°C~50°C | |
Environment temperature | 5°C~50°C | |
Relative humidity | ≤95%(25°C) | |
Water turbidity | <20FTU | |
Wireless Handle | Founction | Wireless controlling waterjet |
Display | Real- time display condition of X,Y,Z axis | |
Settings | Zero point, on/off valve set, X,Y,Z axis moving | |
Technology | Advanced technology |
Advantage:
1.37KW SIEMENS motor
2.All electric components are Schneider brand
3.Can do special size and special design according to customer’s demand
4.Free abrasive sand feeding system
5.We have most convenient automatic abrasive sand removing and recycling system for any brand water jet cutting machine
6.Imported intensifier pump
7.Use 8mm steel to make the cutting table stronger and keep the precision time for whole life
8.Soft cover for linear guider or gear and rack, can effectively prevent dust
9.Install an automatic oil tank for cutting table , no need maintenance of linear guider
10.Legitimate WINDOWS 7 system and install the Chinese newest water jet cutting system
11.TBI linear guider and ball screw
12.Variable servo pump can reduce the electricity cost
13.We have agents in America, Russia, South Africa, Ecuador,UK, Argentina, Chile.Mexico,Australia,Saudi Arabia,Malaysia.Vietnam
14.We can make machine moving speed to 10-50m/min which will improve your cutting efficiency
15.We are finding agent all over the world
1. What are the benefits of purchasing a water jet cutting machine comparing EDM, Laser, Plasma or Machine tool?
Requirements | Waterjet | EDM | Laser | Plasma | Machine tools |
Cost and time efficient | Yes | No | Yes | Yes | No |
High tolerance, precise cutting | Yes | Yes | Yes | No | No |
No burned edges, no HAZ | Yes | No | No | No | Yes |
Multi-head cutting | Yes | No | Yes | No | Yes |
Steel is over 150mm thickness | Yes | Yes | No | Yes | Yes |
No distortion or discoloration | Yes | Yes | No | No | Yes |
Nesting yield | Yes | Yes | Yes | No | No |
Shiny, mirror finish | Yes | Yes | No | No | Yes |
Brittle,soft or hard material | Yes | Yes | Yes | Yes | No |
Stainless steel, copper, brass or exotic material | Yes | Yes | No | Yes | No |
No toxic fumes, deposits, or carbon buildup | Yes | No | No | No | No |
Environmentally friendly | Yes | No | Yes | Yes | No |
2. What kind of material does your water jet cutting machine can cut?
There are plenty materials our water jet cutting machine can cut, such as stone, ceramic, quartz, glass, foam, plastic, rubber, copper, brass, aluminum, mild steel, pre-hardened steel, titanium, inconel and hastalloy
3. What's your cnc water jet cutting machine's max.cutting thickness?
Generally speaking, if cut steel the max thickness of our water jet cutting machine can be up to 240mm, but we suggest cut not more than 150MM for smooth cutting. now our Z axis distance is 170mm, we can do special for customers.
4. How we supply after-service?
Some countries we have after-service department, we will provide local service, if have no local service, we will arrange engineer for overseas installation and training. The installation and training time is generally 7-10 days. And we also can provide installation videos.
5. What's your delivery time?
Generally speaking is 30 days. if have stock, 15 days.
6. what is the cutting speed?
Material | Thickness(mm) | Cutting Speed of 420MPa pump(mm/min) |
Marble | 20 30 | 410 360 |
Granite | 20 30 | 380 250 |
Glass Bridck | 12 | 1100 |
Glass | 5 10 20 | 1610 725 420 |
Glue Chipped Glass | 10 | 630 |
Sponge | 50 | 6500 |
Foam | 50 | 6500 |
Wood | 10 50 | 1350 270 |
Steel | 2 4 6 8 10 15 20 60 | 800 570 520 360 260 150 60 26 |
Laminates | 10 | 2000 |
Aluminum | 5 | 970 |
Copper | 5 | 460 |
Glass Fibre Reinforced plastic | 2 | 1650 |
